AmScope H800 Series Zoom Digital Inspection Monocular Stereo Microscope 0.7X-5X Magnification on Track Stand with 3.1MP USB Camera and Ring Light

This high-speed inspection system includes a zoom monocular microscope, a 96-LED ring-light, and a 3.1MP USB 2.0 camera with frame-rates up to 83fps. The .7X to 5X microscope produces a highly-detailed image -- ideal for industrial or biological inspection. The C-mount camera adds high-speed video and still-image capabilities when used with your computer. The optimized digital sensor and imaging-buffer provide extremely high frame-rates. Using the USB interface for both connectivity and power, only a single cable is needed.

With software available for Windows, Mac, and Linux, this camera package is a multi-platform imaging solution. The included Windows software offers image-development and measurement tools, as well as advanced compositing features such as image-stitching and extended-depth-of-focus. With the ability to calibrate scales at multiple magnifications, the software can be used for multi-level inspection. Independent preview and capture resolutions allow you to view high-speed video while simultaneously capturing high-definition images. For Mac and Linux, there is a lite version of the software which can capture video and still images, and includes limited processing features.

Features:

0.7X-5.0X zoom objective

C-mount lens

Long working distance

Sharp images over a super wide field view

Stable, all-metal pillar-stand

Cool, even 96-LED lighting

Specifications :

Zoom microscope objective: 0.7X-5.0X

Mount: 0.4X C-mount

Working distance: 4-1/8" (105mm)

Field of view: 1/2"x11/16" (12.9mm X 17.1mm) to 5/64"x3/32" (1.8mm X 2.4mm)

Power input: 110-240V, 50-60HZ, auto switching

Metal stand dimension: 13"x10"

Pillar: 11" (280mm) long

Camera Specifications:

Sensor: Aptina MT9T001 (color)

Sensor Type: CMOS

Sensor Size: 6.55x4.92mm (1/2" class)

Pixel Size: 3.2µm

Resolution: 3.1MP

Sensitivity: 1V/lux-sec

Dynamic Range: 61dB

Signal-to-Noise Ratio: 43dB

Frame Rate: 83fps @ 680x510, 43fps @ 1024x768, 12fps @ 2048x1536

Compatibility: Windows (32/64 bit) XP/Vista/7/8/10, Mac OSX, Linux

Software Specifications:

OS Requirements: Windows (32/64 bit) XP/Vista/7/8/10, Mac OS X, Linux kernel 3.13+

Hardware Requirements: Intel Core2 2.8GHz or comparable processor, 2GB RAM, USB3.0 port for maximum speed

Packing List :

One monocular zoom microscope

One focusing rack

One pillar plate stand

One dust cover

One 96-LED Ring Light

One lighting control module

One 3.1 USB 2.0 camera

One USB 2.0 cable

Shipping Weight: 16 lbs
